CD Projection Welder Model: ADR-10000
Equipped with microcomputer control system, accurate output current, stable welding voltage.
It is a fast form of resistance welding by using capacitor discharge, high frequency pulse discharge and instantaneous welding.
The heat is concentrated in the convex points, and the welded joint is stronger.
Agera's ADR-10000 CD Projection Welder
Agera has 24 years of experience in the resistance welding industry, and has been continuously developing and selling this ADR-10000 capacitor energy storage welding machine. We offer a large stock of standard energy storage welds and can also customize tooling for your products on the basis of standard machines. In the field of automation, we are also very professional, can easily help you achieve welding automation, such as integrating a nut conveyor, or suitable for large parts welding conveyor belt.
| Model | ADR-10000 | |
| Energy storage | W.S | 10000 |
| Input power | KVA | 20 |
| Power supply | φ/V/Hz | 3/380/50 |
| Maximum Primary current | A | 52 |
| Primary Cable specification | mm2 | 16㎡ |
| Maximum short circuit current | KA | 80 |
| Rated load duration | % | 50 |
| Welding cylinder specifications | Ø*L | 160*100 |
| Maximum working pressure | N | 12000 |
| Cooling water consumption | L/Min | 8 |
