아연 도금 스팟 용접기

AGERA’s galvanized sheet spot welding machine

produces less spatter, does not stick to the electrode,

and the welded product has a beautiful appearance.

Equipment for spot welding galvanized sheets

AGERA’s galvanized spot welding machine uses a DC power supply 그리고 MFDC 기술, which has a small thermal impact on welding and can reduce overheating of the main cable. This type of welding equipment can also reduce electrode wear, eliminate the need for frequent electrode replacement, and effectively improve welding stability. The power of AGERA’s galvanized sheet spot welding machine is available from 75KVA to 1000KVA, and can be used to weld galvanized sheets or galvanized parts of different thicknesses.

용접기 모델 중 일부

Small Galvanized Spot Welder

This low-power machine can only weld small galvanized parts of about 1 mm and comes with a workbench for convenient placement of workpieces.

지금 문의하기
260KVA Galvanized Spot Welder

This welding machine can be used for spot welding and projection welding, and can easily weld galvanized sheets or galvanized nuts.

지금 문의하기
High Power Galvanized Spot Welder

It can be used for ring projection welding of large galvanized explosion-proof nuts or other large contact surface welding with high current output.

지금 문의하기

Parameter settings for spot welding of galvanized sheet

The main welding parameters that affect spot welding of galvanized sheet are welding current, welding time and welding pressure. Since the galvanized sheet has a zinc layer, we need to set two current modes. The first mode uses a small current and a long time to melt the galvanized layer. The second mode uses a large current for instantaneous welding. In addition, the welding pressure cannot be set too small, which is easy to produce spatter and affect the appearance.

지금 문의하기

Parameter settings for spot welding of galvanized sheet

Precautions when spot welding galvanized sheet

First, we need to clean the workpiece 그리고 remove surface stains or oxide layers to avoid welding defects. In the process of welding galvanized sheet, we must pay attention to controlling the welding temperature to prevent the zinc layer from melting and affecting the welding quality. In addition, we must also pay attention to the maintenance of the electrode, regularly check the electrode wear, and replace the electrode in time.

지금 문의하기

왜 Agera를 선택해야 하나요?

아게라 의 선도적인 제조업체입니다 저항 용접기 중국에서. 우리는 제공합니다 원스톱 저항 용접 솔루션. 당사의 용접기는 신뢰할 수 있는 품질을 갖추고 있으며 ISO 품질 인증 및 세 인증. 우리는 당신에게 신속하게 제공할 수 있을 뿐만 아니라 표준 저항 용접기, 또한 반자동 또는 완전 자동을 사용자 정의할 수 있습니다. 자동 용접 장비 당신을 위한.

Agera는 용접기 구조의 신속한 프로토타입 제작 및 설치를 보장하기 위해 첨단 머시닝 센터를 보유하고 있습니다. 제품 테스트 프로세스 귀하께서 만족스러운 기계를 받으실 수 있도록 최선을 다하겠습니다. 또한, 강력한 기술 팀, 고객님께 더욱 완벽한 기계를 설계하기 위해 R&D와 혁신을 고집합니다. 애프터 서비스 팀 귀하의 정상적인 생산을 항상 지원할 준비가 되어 있습니다.

원스톱 자동 저항 용접기 솔루션

당사의 표준 저항 용접기가 귀하의 요구 사항을 충족하지 못하는 경우 맞춤형으로 제작할 수 있습니다. 자동 용접기 당신을 위한.

최신 가격을 요청하세요

용접기에 대한 추가 정보

동영상
최신 용접 솔루션

Why does my AC spot welder often fail to weld galvanized sheet?

Because the melting point of the zinc layer of the galvanized sheet is low, while the melting point of the base material is high. If you use an AC spot welder to weld, you can only set the welding current once. Therefore, although the zinc layer is melted, the base material is not completely fused. Only using our DC 스팟 용접기 is the best choice for welding galvanized sheet.

What is the reason for the yellowing of the galvanized sheet after welding?

It may be caused by improper parameter settings, too long current output time, or oxidation and corrosion at the welding position.

What type of spot welder is needed to weld 2mm thick galvanized sheet?

당신은 우리의를 사용할 수 있습니다 ADB-130 DC spot welder, which has a rated capacity of 130KVA and can weld 2-3mm thick galvanized sheet.

Does the greater the pressure during galvanized welding, the less spatter?

Although there will be more spatter if the welding pressure is too low, the pressure should be controlled not to be too high. Excessive welding pressure is prone to indentation, affecting the appearance and even crushing the joint.
