AUNS-200 Steel Bar Flash Butt Welding Machine

Using the gas-liquid booster control mode, the output pressure is 4 to 6 times that of the pneumatic mode.

Equipped with removable protective partition to ensure operator safety. Hd display, easy to adjust parameters and data monitoring.

Foot control tool clamping, manual start button, high safety factor.

Agera's Steel Flash Butt Welder

With a welding capacity of up to 900mm², we can customize the right tooling according to the product you need to weld to ensure maximum welding efficiency. Agera’s Steel Flash Butt Welder also has automatic detection function, combined with industrial computer and other equipment components, can monitor welding process parameters in real time, improve the welding yield. Agera can provide a variety of control modes, foot, manual, automatic, push button, pneumatic, pneumatic hydraulic pressurization, motor, hydraulic and other modes can be for you to choose, our technicians will also help you make the best equipment mode choice according to your welding requirements. Agera’s flash butt welding machine is rich in process parameters, suitable for various cross-sectional metal parts connection.

Model Unit ACBS-200
Rated Power KVA 200
Power Supply φ/V/Hz 1/380/50
Rated Load Duration % 50
Cooling Water Flowrate L/Min 12
Maximum Welding Capacity Low Carbon Steel(open loop) 900
Low Carbon Steel(closed loop) 600

Characteristics of Rebar Flashing Butt Welding Machine.

This kind of flash butt welding machine can weld low carbon steel rods with a diameter of 300-900mm², and can also weld other alloy materials. When welding, the spatter extrusion produces a flash phenomenon, and the welded joint can pass the flaw detection test.

Steel Bar Butt Welder

Why Choose Agera?

Agera's resistance welding machine workshop
A batch of custom-made resistance welding machines

Agera is a leading supplier of resistance welding machines in China. Our machines are durable and the internal parts are of the highest quality. Our products have passed CE certification and ISO:9001 quality certification system to ensure your efficient production.

We have rich experience in the resistance welding industry, 50+ patent inventions related to resistance welding, 6000+ customers served, and 50000+ welding cases. Cooperating with Agera, we will provide you with a one-stop welding solution to meet your metal processing needs and improve your market competitiveness.
